100V 2000A Industrial Power Supply Rectifier For Electrolytic Gas

Input parameters: Three phase, AC380V±10% ,50HZ

Output parameters: DC 0~100V 0~10KA

Output mode: Common DC output

Cooling method: Water cooling

Power supply type: IGBT-based

Application Industry: Gas Electrolysis, such as hydrogen, sulfur hexafluoride, carbon tetrafluoride, sulfur hexafluoride, ultra pure ammonia etc.

Description

The electrolytic gas rectifier is mainly used in the electrolytic synthesis of hydrogen, sulfur hexafluoride, carbon tetrafluoride, sulfur hexafluoride, ultra pure ammonia and other special gases.

Features of electrolytic power supply
The electrolytic rectifier is mainly used for Copper Foil Electrolysis,Electrolytic gas,Rare Earth Smelting,etc.
Field application diagram

Sulfur hexafluoride is a colorless, odorless, non-toxic, non-corrosive, non-flammable, insulating and refrigeration gas with extremely high dielectric strength and thermal stability. In the power industry, because of its excellent insulation and arc extinguishing characteristics, widely used in high voltage and medium high voltage circuit breakers and high voltage cables, transformers, transformers, sensors, particle and electron accelerators, X-ray equipment, uHF transmission system. In the semiconductor industry it is used as etching and cleaning gas.

Tetrafluoron is a colorless, odorless, non-flammable, compressible inert gas. It is widely used in silicon, silicon dioxide, silicon nitride, phospho-silicon glass and tungsten film materials candle carving. It is also widely used in electronic device surface cleaning, solar cell production, laser technology, gas phase insulation, cryogenic refrigeration, leak testing agent, space rocket attitude control, detergent in printed circuit production and so on.

Electrolytic synthesis method to produce sulfur hexafluoride technology, the sulfur is directly added to the fluorine electrolytic cell, and is prepared into khF2-HF-S mixture. When electrolytically melting this mixture, the fluorine produced immediately reacts with the sulfur in the electrolyte and generates SF6. After adding the sulfur, the electrolytic voltage of the electrolytic cell does not increase, nor does it cause current loss.

Technical Parameters

Characteristic Types

Parameter Items

Technical Requirements
Power Types  Power types High-frequency Power Supply
Model and specifications TBSB-10KA/100V
Cooling mode Water-cooled
Switch tube type IGBT
Input Characteristics Rated Input Voltage Three-phase, AC380V±10% ,50HZ
Rated Input Power 1111 KW
Rated Input Current AC 1688A
Input Power Factor COSΦ≥0.95
Output Characteristics Output Voltage DC  0~100V
Output Current DC  0~10KA
Stabilized Current Precision ≤1%(Rated Current)
According to accuracy 1A,0.1V
Rated Output efficiency ≥90%
Environmental Conditions Installation site Indoor installations
Altitude ≤1500 meters
Ambient temperature -20℃~40℃
Relative humidity ≤90%
Control Mode Operating mode PLC, ADDA, Ethernet, RS485 and RS232
External Dimension Height*Width*Depth H2200mm×W2500mm×D1450mm
Protection Characteristics With over voltage, over current, overload, short circuit, overheating and other abnormal self-protection function
Optional models
Application Model Output Parameters
Fluoride electrolysis, SF4,SF6 TBSB-9000A/12V 12Vdc/9000A
TBSB-10000A/12V 12Vdc/10000A
TBSB-6000A/15V 15Vdc/6000A
TBFBZ-13000A/9.5V 9.5Vdc/13000A
TBFBZ-13000A/10V 10Vdc/13000A
TBFBZ-15000A/10V 10Vdc/15000A
TBFBZ-18000A/11V 11Vdc/18000A
TBSB-20000A/9V 9Vdc/20000A
TBSB-10000A/15V 15Vdc/10000A
TBSB-12000A/15V 15Vdc12000A
TBSB-24000A/15V 15Vdc/24000A
TDSB-2000A/70V 70Vdc/2000A
TDSB-2000A/90V 90Vdc/2000A
TDSB-3000A/65V 65Vdc/3000A
TDSB-1800A/80V 80Vdc/1800A
TDSB-2000A/100V 100Vdc/2000A
TDSB-6000A/50V 50Vdc/6000A
KES-7000A/150V 150Vdc/7000A
TBSB-12000A/20V 20Vdc/12000A
TBSB-13KA10V 10Vdc/13KA
TBSB-20KA10V 10Vdc/20KA
SF6 TBSB-6000A13V 13Vdc/6000A
TDSB-1500A80V 80Vdc/1500A
Hydrogen electrolysis KES-8.7KA655V 655Vdc/8.7KA
