Characteristic Types
|
Parameter Items
|
Technical Requirements
|
|
Power Types
|
Power types
|
High-frequency Power Supply
|
|
Model and specifications
|
TBSB-2500A/25V
|
|
|
Cooling mode
|
Water-cooled
|
|
|
Switch tube type
|
IGBT
|
|
|
Input Characteristics
|
Rated Input Voltage
|
Three-phase, AC380V±10% ,50HZ
|
|
Rated Input Power
|
70.0 KVA
|
|
|
Rated Input Current
|
AC 106A
|
|
|
Input Power Factor
|
COSΦ≥0.95
|
|
|
Output Characteristics
|
Output Voltage
|
DC 0～25V
|
|
Output Current
|
DC 0～2500A
|
|
|
Stabilized Current Precision
|
≤1%（Rated Current)
|
|
|
According to accuracy
|
0.1A，0.1V
|
|
|
Rated Output efficiency
|
≥91%
|
|
|
Environmental Conditions
|
Installation site
|
Indoor installations
|
|
Altitude
|
≤2000 meters
|
|
|
Ambient temperature
|
-20℃～40℃
|
|
|
Relative humidity
|
≤90％
|
|
|
Control Mode
|
Operating mode
|
PLC, ADDA, Ethernet, RS485 and RS232 available
|
|
External Dimension
|
Height*Width*Depth
|
H185mm×W402mm×D640mm
|
|
Protection Characteristics
|
With over voltage, over current, overload, short circuit, overheating and other abnormal self-protection function
|
|
|
*OK to Customized according to requirements*
|
||
