Input parameters: Three-phase AC380V ± 10% 50 - 60Hz, Compliance with National Power Quality Standards
Output parameters: DC 0~6V 0~500A
Output mode: Ordinary direct current
Cooling method: Water cooling
Power supply type: Synchronous rectifier power source
Application Industry: Non-ferrous metal electrolysis, such as electrolytic silver, copper and aluminum
After the AC input voltage is filtered by the rectifier circuit, the high-voltage DC power is obtained. The 500A 6V Electrolytic Silver Rectifier Power Supply for Silver Electrolysis uses “variable frequency conversion” to invert the high-voltage direct current into about 30kHz high-frequency alternating current, which is then converted into the secondary voltage by a high-frequency transformer, and then filtered by the high-frequency rectifier circuit to obtain the required output voltage. Sampling of output voltage and current is made by the control circuit, and then the signal of pulse width modulation (PWM) for controlling the inverter circuit is generated after closed-loop feedback to keep the output voltage and current steady.
The TBSBZ-500A/6V is ideal for high-purity silver refining (up to 99.99%), silver electrowinning from solutions, silver recovery from scrap or photographic waste, laboratory-scale silver electrolysis research, and small to medium-scale precious metal refineries.
› High Reliability
› Easy to use and repair
› Fault Self-diagnosis
› High accuracy of steady flow
› Soft startup, soft shutdown
› On/Off loop disturbance-free switch
› High efficiency (≥91%)
› Low ripple (≤3%)
› Compact & lightweight
› Water-cooled
› RS485 remote control
| Type of characteristics | Parameters | Technical Requirements |
| Input characteristics | Rated input voltage | Three-phase AC380V ± 10% 50 – 60Hz, Compliance with National Power Quality Standards |
| Rated input current | AC 4.8A | |
| Rated input power | 3.5 KVA | |
| Rated input power factor | COSΦ≥0.95 | |
| Output characteristics | Output voltage | DC 0～6V (Adjustable from 1% to 100%) |
| Output current | DC 0～500A(Adjustable from 1% to 100%) | |
| Precision of steady current | ≤1% | |
| Precision of stable voltage | ≤1% | |
| Displayed precision | 1A，0.01V | |
| Current ripple coefficient | ≤3%（I≥50%Id） | |
| Rated output power | ≥91% | |
| Insulation characteristic | Insulation resistance | Input – Output: ≥5MΩ |
| Input – Cabinet: ≥5MΩ | ||
| Output – Cabinet: ≥5MΩ | ||
| Protective characteristics | With self-protection function under non-normal cases such as over-voltage, over-current, overload, short circuit and overheating | |
| Other characteristics | Noise | ≤60dB |
| Running state | Continuous full load run of product | |
| Load level | Level II | |
| Insulation grade of the transformer | Grade B | |
| Weight | 20kg | |
If you need other electrolytic silver rectifiers, we can custom design them according to customer requirements. Please contact us.
Looking for a 500A 6V electrolytic rectifier power supply for silver electrolysis? Liyuan Haina Group, a professional manufacturer with 27+ years specializing in industrial rectifiers, supplies global clients including the United States, Canada, Britain, Italy, Spain, South Africa, Russia, the UAE, Japan, South Korea, Malaysia, etc. Our advanced factory delivers cost-effective Made-in-China solutions, with competitive prices and customizable options. Contact us for sales inquiries.
